LY Taber Abrasion Tester with 12 Months Warranty ASTM D4060/D4157/D1044 Standard and Test Load 250g-1000g for Fabric Abrasion Testing

Name: LY Taber Abrasion Tester with 12 Months Warranty ASTM D4060D4157D1044 Standard and Test Load 250g1000g for Fabric Abrasion Testing
Brand: LIYI
Price: 1 USD

LY Taber Abrasion Tester with 12 Months Warranty ASTM D4060/D4157/D1044 Standard and Test Load 250g-1000g for Fabric Abrasion Testing Manufactures

Brand Name : LIYI

Place of Origin : Guangdong, China

MOQ : 1

Test load : 250g,500g,750g,1000g

Weight : 18kg

Center space : 63.5mm

Specimen dimension : φ110mm φ6mm

Grinding wheel : φ2″(MAX .45mm)1/2″(W)

Wheel distance : 37~38mm

Rotating speed : 60rpm 72rpm

Timer : LCD,0~999999

Dust collector distance : 3mm

Dimension : 53*32*31cm

Power : 1phase,AC220V,50HZ

Grinding wheel pair : Imported

Wheel center space : 63.5mm

Sample thickness : φ6mm

Wheel width : 1/2″

Contact Now

LY Taber Abrasion Tester Taber Coating Wear Abrasion Testing Machine Fabric Abrasion Tester

Product Description

This machine is used to do the test of wear-resistant in surface, leather, cloth, paint, paper, flooring, plywood, glass and natural rubber,concrete and ceramics. The method is using the standard knife cutting the specimen, and then using the regulated models of grinding wheel with loading weight to be abrased. Remove the specimen after rotation to reach a centain number, and then observe the condition of the specimen or compare the weight with the previous materials. Test Standard: ASTM D4060/D4157/D1044, JIS K5400/K7024, CNS 8540, BS EN 660-2

Specifications

Specimen dimension	φ110mm φ6mm
Grinding wheel	φ2″(MAX .45mm)1/2″(W)
Center space of wheel	63.5mm
Distance between wheel and test plate	37~38mm
Rotating speed	60rpm 72rpm
Load	250g,500g,750g,1000g
Timer	LCD,0~999999
Distance between sample and dust collector	3mm
Dimension	533231cm
Weight	18kg, Excluding dust collector
Power	1phase,AC220V,50HZ
Accessories	Imported grinding wheel 1 pair

Products Detail

LY Taber Abrasion Tester with 12 Months Warranty ASTM D4060/D4157/D1044 Standard and Test Load 250g-1000g for Fabric Abrasion Testing

Related Products

Company Profile

Dongguan Liyi Environmental Technology Co., Ltd is a high technology supported production-oriented enterprise who specializes in developing, manufacturing, marketing all kinds of environmental equipment. Our company has advanced technology, experienced technical management personnel and efficient professional service staffs, fine quality management and perfect after-sales service system.

Our company mainly produce simulated environmental tester, plastic and rubber tester etc. on all kinds of materials testing industries. The production base is located in the country’s manufacturing center Dongguan, Guangdong province, China. In order to service our customers better in terms of reducing costs and early delivery, in 2005 we had set up an office in Kunshan, Jiangsu province for Eastern China marketing and servicing.

Liyi deals with customers from more than 150 countries and regions. Meanwhile, we are committed to cooperate with different dealers in different countries and regions in order to offer better service. Our mission is to help every customers establish testing labs to ensure the quality of their products.

Our company will continue to develop, innovate and keep faith. We combine with the international testing standards and the specific demands of customers that may establish a new banner in Chinese testing industry.

FAQ

1. Are you Manufacturer?Do you offer after-sales service? How can I ask for that? And how about the warranty?
Yes, we are the one of professional and biggest Manufacturer like Environmental Chambers, Industrial Ovens, Universal Tensile Testers, UV Aging Test Chambers, Industrial Muffle Furnaces, Paper Packing Testers, Plastic Rubber Testers, Adhesive testers and other testing Equipment.. in China .Every machines purchasing from our factory has 12 months warranty after shipment. Generally, we offer 12 months for the FREE maintenance. while considering of sea transportation,we can extend 2 months for our customers.

Moreover, If your machine doesn’t work, you can send us an E-mail or call us we will try our best to find the problem through our conversation or by video chat if neccesary. Once we have confirmed the problem, the solution will be offered within 24 to 48 hours.

2. What’s the delivery term?
For our standard machine which means normal machines, we have stock in the warehouse. If there is no stock, normally, the delivery time is 15-20 working days after deposit receipt ( this is only for our standard machines) If you are in urgent need, we will making a special arrangement for you.

3. Do you accept customization service? Can I have my logo on the machine?
Yes, of course. We can not only offer standard machines, but also customized machines according to your requirements. And we can also put your logo on the machine which means we offer OEM and ODM service.

4.How can I install and use the machine?

Once you have ordered the testing machines from us, we will send you the operation video in English version through Email.

Most of our machine is shipped with a whole part, which means it is already installed, you just need to connect the power cable and start to use. And if it's necessary, we can also assist you to install your machine on site.
